Alto

RAIN SKY A5

 RAIN SKY A5 VERSIONS

Click on the length of the hose to download the rainfall chart!

 MODEL

50 F

63 F

 BASE

A5

A5

 HOSE DIAMETER

50

63

 HOSE LENGTH

150 - 180 - 200

110

SPECIFICS: Turbine driven, model 3/20 - 100

STANDARD EQUIPMENT

  • 4 meters rubber supply hose with couplers.

  • Standard trolley with wheels.

  • Standard sprinkler with nozzles.

  • Crank for winding in hose.

  • Operator's manual and spare parts list.

  • Pressure gauge in glycerine bath and gauge cock.

EXTRAS

  • STEEL DOUBLE SUPPLY PIPE. Eases the supply of water to the hose reel in all working positions.

  • DISCHARGE VALVE. Stops the motor pump by creating a sudden pressure loss.

  • SHUT-OFF VALVE. Stops irrigation by creating a rise in pressure.

  • SHUT-OFF VALVE WITH PROGRAMMABLE ELECTRIC MOTOR. 4 different shut down speeds to avoid any water hammer.

  • TURNTABLE ROTATION KIT used to turn the turntable easily to the required position.

  • PTO WIND-IN KIT used for winding-in hose with a tractor pto. Standard fitting on machines with turbine, optional extra machines with bellow driving system.

  • HYDRAULIC KIT allows to use the hydraulic system of the tractor to drive the standing foot, the stabilizing legs, the trolley lifting system and the drum rotation.

  • GALVANISING recommended for machines spreading slurry and dirty water.

  • ROAD OMOLOGATION with certificate of conformity.

  • ENGINE DRIVEN INDEPENDENT HYDRAULIC KIT. Allows the movements hydraulically by means of a small diesel or petrol engine.

  • ALTERNATOR for battery recharge with regulation circuit.

  • MANUAL HYDRAULIC KIT for lifting trolley and anchor stabilizing legs.

  • TROLLEY FOR OVER FOLIAGE IRRIGATION

  • TROLLEY FOR IRRIGATION UNDER FOLIAGE LEVEL

  • AUXILIARY GUN connected to the dosidis, allows accurate irrigation of the last twenty meters around the hose reel.

  • HYDRAULIC PUMP ON BOARD driven by PTO of the tractor allowing machine's movements.

  • AIR COMPRESSOR used for blowing air into the hose to empty the machine from water.

  • REMOTE CONTROL for hydraulic kit.

  • GSM MODULE DOSIDIS allows  the check of the set parameters and modify them from remote via SMS text messaging
